Arburg - Allrounder 470 S 1300-350DE-INJ-ARB-2005-00002

Name: Arburg Allrounder 470 S 1300-350
Brand: Arburg
SKU: DE-INJ-ARB-2005-00002
Price: 9000 EUR
Availability: InStock

9,000 €

gindumac price

(Ex works)

get an official quote

Visit the machine

make a counteroffer

Download PDF

Do you have further questions? Contact us.

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Plastics Processing Machinery
➤ Used Arburg Allrounder 470 S 1300-350 For Sale

This Arburg Allrounder 470 S 1300-350 was manufactured in 2005. It is a hydraulic injection moulding machine, ideal for precision plastic processing. Consider the opportunity to buy this Arburg Allrounder 470 S 1300-350 hydraulic injection moulding machine. Contact us for more information.

Overview

brand: Arburg
year: 2005
MODEL: Allrounder 470 S 1300-350
application type: Injection Moulding
Location: Germany
machine type: Hydraulic Injection Moulding Machine
availability: Immediately

Technical Information - Arburg Allrounder 470 S 1300-350

General Data

Measurements width: 3750 MM
Measurements depth: 5750 MM

Injection Unit

Screw diameter: 35 mm
Stroke volume: 139 ccm CM³
Injection pressure: 2500 bar

Clamping unit

Clamping force: 130 kn
Max open daylight: 579 mm
Distance between bars: 470 mm
Mould height min: 273 mm

Additional Equipment

- Wittmann W721-0130 extraction unit
- 4x temperature control units: HB-Therm Thermo 5
- Epson robots for selection

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Injection size: 350
- - Maximum plate distance: 852 mm
- - Valve gate: 2
- - Temperature control units: 4 with a maximum temperature of 160°c each
- - Number of hydraulic core pulls (moving side): 1
- - Interface coloring device: yes
- - The robot is a w721 with a payload of 30 kg, axes x, y, z, c, b, 8 vacuum circles, 3 gripper circles, a quick coupling qca90, and a sub-d communication connector.
- - Automation integrated
- - Automatisation a6 lamellen with epson
- - Oil filling quantity: 250 l
Qualitative Machine Benefits:
- - Cable cross-section: 5x50 / 5x35 mm²
- - Water connection details: size 3/4 inch, 2x2 points

Extra information

- Machine still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
