DMG MORI - CNC 400PL-TUR-FAM-1998-00001
Do you have further questions? Contact us.
Borja Garcia
+34 679 019 350
b.garcia@gindumac.com
- GINDUMAC
- Products
- Machine Tools
- FAMOT CNC 400 Lathe
This DMG MORI CNC 400 Lathe was manufactured in 1998 in Poland and is equipped with a SIEMENS SINUMERIK 810D Control unit. This 2-axis machine comes with a hydraulic chuck as additional equipment.
Overview
- brand: DMG MORI
- year: 1998
- MODEL: CNC 400
- application type: Turning
- Location: Poland
- machine type: Horizontal Turning Machine
- availability: Sold
- control unit brand: SIEMENS
Technical Information - DMG MORI CNC 400
General Data
- Measurements width: 4300 mm
- Measurements depth: 1730 mm
- Measurements height: 1850 mm
- Machine weight: 4500 kg
Control Unit
- Brand: Siemens
- Model: SINUMERIK 810D
Main drive
- Number of spindles: 1
- Spindle speed range: 4000 1/min
Movement
- X-AXIS Movement: 200 mm
- Y-AXIS Movement: 40 mm
- Z-AXIS Movement: 640 mm
Turret
- Number of turrets: 12
Media
- Main electronic connection: 380 V / 50 Hz
- Power consumption: 25 kVA
Additional Equipment
- - Hydraulic Chuck
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
Borja Garcia
Payment Terms
Payment in advance
Asset Financing
