TOS WHN 130 MC Boring Machine

This TOS WHN 130 MC Boring Machine was manufactured in 2003 in the Czech Republic and has a production record of 40000 working hours. Equipped with a HEIDENHAIN iTNC 430 Control unit, this machine has mainly worked with steel and stainless steel during the past. This model stands out due to its two tables with continuous movement driven with 2 pinions. It also incorporates an automatic tool changer with 60 tools positions. Must be noted that this machine cools through its spindle (20 bars). It presents an overall excellent condition, as it was regularly serviced by TOS techincians.

Overview

brand: TOS
year: 2003
MODEL: WHN 130 MC
production hours: 40000
application type: Other Machine Tools
Location: Poland
machine type: Boring Machine (Metal)
availability: Sold
control unit brand: HEIDENHAIN

Technical Information - TOS WHN 130 MC

General Data

Measurements width: 7300 mm
Measurements depth: 6300 mm
Measurements height: 4550 mm
Machine weight: 38000 kg

Control Unit

Model: iTNC 430
CNC main language: English
CNC language customizable: Yes
Brand: HEIDENHAIN

Main drive

Spindle speed range: 2500 1/min

Movement

X-AXIS Movement: 3000 mm
Y-AXIS Movement: 2240 mm
Z-AXIS Movement: 1250 mm
W-Axis Movement: 800 mm

Workpiece

Workpiece weight: 8000 kg

Table

Outer length: 1600 mm
Outer width: 1800 mm

Media

Power consumption: 86 kVA
Oil water separator: Yes
Chip conveyor: Yes

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
