Trumpf TruMark 5000 Laser cutting machine

This Trumpf TruMark 5000 Laser cutting machine was manufactured in the year 2006 and has 48000 production hours. The machine has a workpiece weight of 10 kg.

Overview

brand: TRUMPF
year: 2006
MODEL: TruMark 5000
production hours: 48000
application type: Other Sheet Metal Machinery
Location: Austria
machine type: Laser Marking Machine
availability: Sold

Technical Information - TRUMPF TruMark 5000

General Data

Measurements width: 1630 mm
Measurements depth: 1000 mm
Measurements height: 1790 mm
Machine weight: 420 kg

Main drive

Spindle speed range: 14 1/MIN
Laserpower: 2 kW

Workpiece

Workpiece weight: 10 kg

Media

Main electronic connection: 230 V / 50-60 Hz

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Da 150 trumark station + 3 jaws chuck
- - Rotary axis for circumferential marking
- - Diameter d : 150 mm
- - Center height 75 mm
- - Center passage 60 mm
- - Resolution 0,0125 °
- - Repeating accuracy o, 125°.
- - Axial load 700 n, radial load 250 n
- - Tangential torque 15 nm, max. Tilting moment 25 nm
- - With stepper motor
Qualitative Machine Benefits:
- - Protective filter 200x 1oomm ( 1064nm)
- - Protected on the laser side with a plexiglas against damage

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
