Emco Maxxmill 350 Vertical Machining center

This Emco Maxxmill 350 Vertical Machining center was made in 2015 in Italy and has 14615 production hours. It is equipped with a HEIDENHAIN TNC 620 control unit and has 3+2 axis. The machine has a spindle speed of 12000 rpm, is in good condition and well maintained.

Overview

brand: EMCO
year: 2015
MODEL: Maxxmill 350
production hours: 14615
application type: Milling
Location: Germany
machine type: Vertical Machining Centre
availability: Sold
control unit brand: HEIDENHAIN

Technical Information - EMCO Maxxmill 350

General Data

Measurements width: 1630 mm
Measurements depth: 2300 mm
Measurements height: 2282 mm
Machine weight: 3300 kg

Control Unit

Model: TNC 620
Brand: HEIDENHAIN

Main drive

Number of spindles: 1
Spindle speed range: 12000 1/MIN
Spindle motor power: 7 kW
Number of axis: 3+2

Movement

X-AXIS Movement: 350 mm
Y-AXIS Movement: 250 mm
Z-AXIS Movement: 300 mm

Workpiece

Workpiece weight: 50 kg

Table

Outer length: 400 mm
Outer width: 400 mm

Tools

Slots in storage: 50
Max weight: 5 kg
Max tool diameter: 63/100 mm
Max tool length: 200 mm
Type of tool holder: DIN 30

Additional Information

Machine Benefits

Technical Machine Benefits:
- - B axis: +/- 100 degrees
- - 3+2 axis
- - C axis: 360 degrees (0. 001 degree increment)
- - Min - max height under spindle: 70 - 370mm
- - Rapid feed rates: 30m/minute
- - Swarf conveyor
Qualitative Machine Benefits:
- - Very good condition with low hours!

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
